Page 144 - WERA katalógus

KOLOSS

The ratchet with hammer function

8002 C Koloss ½" SB with ½" drive

? Why has Wera invented

Application: Ratchet function for ½" square sockets and ½" adaptors with the KOLOSS?
square drive, equipped with ball lock, hammer function e.g. to
align work pieces
Design: Push-through square drive for forward and reverse operation, Many users reported that they had
fi ne-tooth ratchet mechanism, small return angle of 6°, can occasionally misused their ratchet as
transfer at least 600 Nm of torque, tubular shaft to minimise a hammer. Unfortunately, the ratchet
impact vibrations, drop-forged hammer head, positively pinned,
ground striking face head is often damaged during this
use. The KOLOSS solves this problem:
Handle: Multi-component Kraftform handle for optimum pressure,
impact and tensile loads, handle end designed for connection at last, a ratchet with a licence to
of KOLOSS extension 8780 C and KOLOSS centring pin 8781 C hammer!

Code
05073232001 8000 HLF 1 x Holster 1
? Why do the dual ratchet teeth
8002 C 1 x 1/2"x341,0
8782 C 1 x 2x50,0

provide particular robustness?

Dual ratchet teeth: gives the
robust 30 saw teeth the precision
engineering eff ect of 60 fi ne teeth
with a 6° return angle.

140
