ELECTRONICS PLIERS

Electronics Diagonal Cutters
DIN ISO 9654 75

> bolted joint for high precision and stress tolerance
> for ultra fine cutting work, e g in electronics and fine mechanics
> with sharp, ground cutting edges for soft and hard wire and piano wire
> cutting edges additionally induction hardened,
cutting edge hardness approx 6 HRC 75 02 125
> low friction double spring for gentle and even opening
> High grade special tool steel, forged, multi stage oil hardened

Style 0
with bevel
Style 1
with bevel and lead catcher, no
uncontrolled loss of cut wire ends
Style 2
with small bevel 75 12 125 75 22 125

Style 5
particularly narrow head, with bevel

75 52 125

$olted joint

Cutting capacities Dimensions
EAN A $ D
Article No 003773 mm Style Pliers Handles Ø mm Ø mm Ø mm Ø mm mm mm mm g
75 02 125 0 0 91 125 0 burnished with plastic grips 0 2 1 3 1 0 0 6 0 10 5 1 0 6 5 81
75 12 125 0 051 125 1 burnished with plastic grips 0 2 1 3 1 0 0 6 0 10 5 1 0 6 5 80
75 22 125 0 0538 125 2 burnished with plastic grips 0 2 1 3 0 9 0 0 3 10 5 1 0 6 5 79
75 52 125 0 0576 125 5 burnished with plastic grips 0 2 0 8 0 5 0 3 10 5 1 0 6 5 79

238
