CRIMPING PLIERS

Tool Case for Photovoltaics, 97
MC3 (Multi-Contact) 91

> the complete tool set to install MC3 connectors
> with service tools (hexagonal key) for the change of crimping dies
shock resistant plastic case
> foam inserts with recesses for the tools, crimping dies and locators
> with four empty plastic boxes for consumables;
for individual equipping 97 91 02
> dimensions, exterior (W x H x D): 360 x 105 x 300 mm

EAN
Article No 003773 Quantity g
97 91 02 07 083 Tool Case for Photovoltaics, MC3 (Multi Contact) 3280
12 12 11 Precision Insulation Stripper, with adapted blades 1
95 16 165 Cable Shears 1

97 3 200 Crimp System Pliers, for exchangeable crimping dies 1
97 9 65 Crimping dies, for solar cable connectors MC3 (Multi Contact) 1
97 9 65 1 Locator for 97 9 65 (solar cable connectors MC3) 1
97 9 65 2 Mounting Tool for MC3 connectors 1

Mounting Tool for MC3 connectors 97

> for easy and quick assembly of MC3 solar cable connectors
> for fit solar sleeves for connectors from 2 5 to 10 mm²
> three capsules (2 5 / ; 6; 10 mm²) for pulling on the
sleeves, integrated in the detachable handle
> body: plastic, fibreglass reinforced
97 49 65 2

EAN Capacity
Article No 003773 mm mm² g
97 49 65 2 072010 325 2 5 10 60
The assembly tool comes with three torpedo mandrels for the various cable cross sections

Set of Mounting Tools
for solar cable connectors MC4 (Multi-Contact) 97

> set of two mounting tools
> to tighten cable glands of MC solar plugs
> to open the locking of MC housings 97 49 66 2
(even in case of mounted lock clip)
> tool: plastic, fibreglass reinforced EAN
Article No 003773 mm g
97 49 66 2 07 106 115 18
