P. 225

WATERPUMP PLIERS


                 KNIPEX Alligator  XL
                                    ®
                 Pipe Wrench and Water Pump Pliers
                 DIN ISO 5743                                   88


                The classic in 400 mm length
                4QDWUV EQPUVTWEVKQP  KPUGPUKVKXG VQ FKTV
                particularly suitable for outdoor work
                   > good access to the workpiece due to slim size in the
                 head and joint area
                   > guard prevents operators‘ fingers being pinched  88 01 400
                   > Chrome vanadium electric steel, forged, multi stage oil hardened




                                                                                     ®
                                                                       The KNIPEX Alligator  XL offers the performance and comfort of a
                                                                       YCVGT RWOR RNKGTU YJKNG DGKPI      NKIJVGT KP YGKIJV CPF JCXKPI C
                                                                       greater gripping capacity (3 ½") than comparable pipe wrenches.
                                                                       With their handy length of 400 mm, there is a place for KNIPEX
                                                                       Alligator  :. KP GXGT[ VQQN DQZ
                                                                             ®














                Robust pliers for very hard applications


                gripping surfaces with special hardened teeth, teeth hardness approx  61 HRC:
                low wear and stable gripping



                self locking on pipes and nuts:
                no slipping on the workpiece and low handforce required



                box joint design: high stability because of the double guide







                robust adjustment mechanism, insensitive to dirt, easy to clean;
                particularly suitable for outdoor work




                11 notch adjustment for a gripping capacity up to 3 ™",
                optimised adjustment to the workpiece and a comfortable handle position







                         EAN                                                                               Adjustment
                 Article No    003773   mm  Pliers         Head    Handles               Ø Inch  Ø mm  mm   positions  g
                 88 01 400  0758     00     black atramentized  polished  with non slip plastic coating  3 1/2  90  95  11  1190
