Page 287 - Wiha catalogue 2022

Automatic crimp tool Crimping tools

for insulated terminals and connectors Z 62 0 06
For wire-end sleeves square crimping with Order-No.
rotating crimping head Z 62 0 06
33841 220 0.5 - 6 20 - 10 1
Order-No.
For processing of red, blue and yellow isolated terminals, pin-end termi-
45223 193 0.08 - 16 28 - 5 1 nals, contact pins, contact pin sleeves, circular pins, circular pin sleeves, batch connec-
tors and parallel connectors according to DIN 46234.
For processing wire-end sleeves with and without insulating collar as per DIN 46228, EN 50027.

Crimping tools Crimping tools

for wire-end sleeves Z 62 0 06
for non-insulated cable eye with closed sleeve Z 62 0 06
Order-No. Order-No.
0.14
33844 220 26 - 5 - 1 33843 220 0.1 - 16 26 - 6 1
- 16
For processing of non-isolated cable eyes, pin-end cable connectors, batch connec-
0.14
40342 220 26 - 5 x 1 tors and mini cable eyes according to DIN 46234/ DIN 46230/ DIN 46341.
- 16
For processing wire-end sleeves with and without insulating collar as per DIN 46228, EN 50027.

287
