Page 105 - weller
P. 105
WT Line | Soldering Iron
WP 200 Set
Soldering Stations
Soldering iron WP 200 with safety rest
200 W Power Response XHT
Soldering iron and safety rest
Order No. T005 29 200 99N
Soldering Iron 200 W, 24 V
For large components (Shielding) with high energy demand
Most efficient soldering iron for WT stations and WR rework
stations
Interchangeable XHT soldering tips at low cost prices Soldering tips and nozzles
Power Response heating technology with improved sensor
position
Fast reaction time
Preheating plates
Scope of supply Order No. Model Description
T005 15 158 99N WDH 31 Safety rest with dry cleaner for WP 200 and WXP 200 soldering
iron
T005 29 199 99N WP 200 Soldering iron 200 W, 24 V with Power-Response Heating
Technology
T005 44 801 99 XHT D Soldering tip, chisel, 5,0 x 1,2 mm Soldering bathes
Accessories Order No. Model Description
T005 87 637 25N Barrel WP/WXP 200 Barrel for WP 200 and WXP 200
Circuit board holder
T005 87 637 72N BARREL OPEN Barrel open WP/WXP 200 replacement
WP 200 / WXP 200
Solder feeder
Hot air heating gun
Temperature measuring
Accessories
Soldering Equipment 105
