Instrumentation & Sensor Bars

IQ Power & IQ Easy Sensor Bars
TM
TM
The IQ Power HL and IQ Easy Sensor Bars work with the IQ Power Control
Station to provide the following features:
• In-Process static level measurement
• User-settable alarm outputs
• Closed-loop feedback
• Data and event logging
• Easy convenient data storage and retrieval via anybus or USB

Data storage is valuable as a diagnostic tool for R&D and process
improvement. Historical data can be used to investigate a re/safety
incident or customer complaints and quality issues.

FMX-004

Simco-Ion’s FMX-004 measures both positive and negative polarity charges up to ±30 kV (30,000V) at a distance of 1”.
Results are simultaneously shown numerically and in bar graph format on the unique multi-colored display that also displays
battery charge status. Power on/o , zero adjustment, Ion Balance (MODE) and hold are all push button operation. The hold
button allows the display to retain the static charge reading. This is especially useful where the display is di cult to see
during measurement.
• Lightweight, compact design
• Range light assures accurate and repeatable measurements
• Automatic power o without activity

Speci cations

Power 9V battery
Display Features Push button POWER, HOLD, ZERO, MODE (Ion Balance operation)
Read Out Bar graph: Red LCD for positive polarity voltage; Blue LCD for negative; battery capacity & error display
Measurement Auto Ranging: HI 0 to ±30 kV; LOW 0 to ±3 kV; Ion Balance 0 to ±300V Optional Analog
Output
Distance 1”±1/64” (25 mm ± 0.5 mm); LEDs guide for correct distance
Dimensions 4-7/8”L x 2-7/8”W x 1”D (123 x 73 x 25 mm)

TensION

Simco-Ion’s TensION Voltage Detector enables you to check both AC & DC neutralizing and charging equipment. Without
making contact with the actual equipment it gives you an easy and safe way to check if a high voltage is present. The tip of
the TensION illuminates when a voltage is detected, providing an immediate indication the equipment is energized.
• No contact required
• Safe operation

Speci cations
Power Two AAA size replaceable batteries 1.5V (included)
Temperature -10ºC to +50ºC
Enclosure Radilon-S HS(a), BE 170MO IP64
Dimensions 148L x 17 dia. mm (5.8” x 0.7”)
Certi cations

21
