Perforated back and wall panels

The perforated back panels are fastened to the upright 1. Perforated panels for upright tubes
tubes or straight to TPH bench with panel hooks. The Name Module Size W x H mm Code
perforated wall panels are attached, either directly to the Perforated back panel M500 468 x 389 861 501-49
wall with screws or to the upright profiles with fastening Perforated back panel M750 718 x 194 861 510-07
clips. The size of the pe rforation is 9 x 9 mm, centre to Perforated back panel M750 718 x 389 861 511-49
centre 38 mm. Perforated back panel M750 718 x 612 861 512-07/-49
Perforated back panel, M750 718 x 612 861 701-07/-49
insulated
Perforated back panel M750 718 x 1003 861 514-07/-49
Perforated back panel M900 871 x 389 861 516-49
1 2 Perforated back panel M900 871 x 612 861 517-07/49
Perforated back panel M900 871 x 1003 861 519-07/49
Perforated back panel M1000 968 x 389 861 532-49
Perforated back panel M1000 968 x 612 861 538-07/49
Perforated back panel M1000 968 x 1003 861 535-07
Perforated back panel M1200 1168 x 389 861 533-49
Perforated back panel M1350 1318 x 389 861 521-49
Perforated back panel M1500 1474 x 389 861 526-49
Perforated back panel M1800 1774 x 389 861 531-49
Fastened to the upright tubes (see page 24).
3
2. Back panels for upright tubes
Name Module Size W x H mm Code
Back panel M500 468 x 389 861 541-49
PERFORATED PANELS AND TOOL STORAGE SYSTEMS Back and wall panels
Back panel M750 718 x 194 861 550-49
Back panel M750 718 x 389 861 551-49
Back panel M750 718 x 612 861 552-49
Back panel M900 871 x 389 861 556-49
Fastened to the upright tubes (see page 24).
4

3. Perforated panels for TPH benches
Size W x H mm Suitable for Code
1115 x 750 TPH712 RL120
1415 x 750 TPH715/ 915 RL150
1715 x 750 TPH718/ 918 RL180
The colour code is included in Panel hooks TPH RK1
those product codes that are Mount on TPH benches with panel hooks RK1. Can also be attached to a
formed with numbers. wall with screws (included).
It is either at the end, following
the hyphen (e.g. 860 804-49), 4. Perforated wall panels fastened to the wall
or in the middle Name Size W x H mm Code
(e.g. C 334 07 000).
Perforated wall panel 454 x 988 837 369-07
Perforated wall panel 949 x 988 837 334-07
Perforated wall panel 949 x 1444 837 342-07
Perforated wall panel 949 x 1976 837 350-07
Fastened directly to the wall using screws.
