Packing material roll stands

and cutters

High packing material roll stand
Size Module Max roll Code
W x D x H mm width mm
1380 x 715 x 1500 M1350 1200 890 520-49P
1530 x 715 x 1500 M1500 1400 890 521-49P
1830 x 715 x 1500 M1800 1700 890 522-49P
High stand for two rolls. The rolls are adjustable in height. Axle diameter 25
mm. Max roll Ø 800 mm. Can be equipped with extra roll holder set, castor
set and cutter PPC. Max load 40 kg per roll.

Low packing material roll stand
Size Module Max roll Code
High packing material roll and W x D x H mm width mm
Bracket pair for cutter (page 65) 1380 x 715 x 1000 M1350 1200 859 103-49P
1530 x 715 x 1000 M1500 1400 859 105-49P
1830 x 715 x 1000 M1800 1700 859 108-49P
Low stand for one roll. The roll is adjustable in height. Axle diameter 25 mm.
Max roll Ø 800 mm. Can be equipped with extra roll holder set, castor set
and cutter PPC. Max load 40 kg per roll.

WORKBENCH ACCESSORIES Packing material roll stands and cutters

Low packing material roll stand

Castor set for packing material roll stands
Size mm Code
Ø 100 834 734-00
4 swivel castors Ø 100 mm, 2 with brakes. Attached directly to the stands.

Castor set for packing material roll stands
Extra roll holder set
Module Max roll width mm Code
M1350 1200 859 040-49P
M1500 1400 859 041-49P
M1800 1700 859 042-49P
Extra roll holder set for packing material roll stands. Including brackets. Axle
diameter 25 mm, zinc electroplated. Max load 40 kg.
Extra roll holder set

64 Treston - Ergonomic workspaces
