Perforated industrial screens

These industrial screens are modular, and they can be
equipped with all M750 accessories. Industrial screens
can be used as space dividers. They also provide noise
insulation; the combinations available have perforated
back panels on both sides and one side is insulated.

Industrial screens
Name Size W x D x H mm Code
Standard part, T-feet 780 x 60 x 1850 C 520 07 101 Standard part, T-feet Extension part, T-foot
Extension part, T-foot 750 x 560 x 1850 C 520 07 102
Extension part, L-foot 750 x 310 x 1850 C 520 07 103
Extension part, I-foot 750 x 60 x 1850 C 520 07 104
Includes 6 perforated back panels, 3 pcs/side.
The standard part includes two feet.
The extension part includes one foot.

Parts
Name Size W x D x H mm Code
T-foot 1850 836 516-49
L-foot 1850 836 532-49
I-foot 1850 836 597-49
Spacer bar 750 835 838-49 Extension part, L-foot Extension part, I-foot
Corner joint pair 847 615-51
Perforated back panel M750 718 x 17 x 612 861 512-07/-49
Perforated back panel M750, 718 x 17 x 612 861 701-07/-49
insulated* ! The colour code is included in those product
Upper list 718 x 65 851 907-07 codes that are formed with numbers.
The wall module requires two spacer bars.
It is either at the end, following the hyphen (e.g. 860 804-49), or
* The insulation material used is polyether foam. in the middle (e.g. C 334 07 000).
All M750 accessories are suitable for the industrial screen.

Industrial screen accessories
Name Size W x D mm Max load kg Code
Steel shelf M750 740 x 300 50 836 028-49
Steel shelf M750 740 x 400 50 852 770-49 STORAGE SOLUTIONS Perforated industrial screens
Bin rail M750 742 x 100 50 859 151-49 Steel shelf
PERFORATED PANELS PERFORATED PANELS ! More accessories starting from page 42 Bin rail M750 with brackets and stacking bins.

M750 accessories suit these industrial screens.
