Perforated panels

The perforated back panels are fastened either to the upright tubes (with Concept, LMT and TP benches) or accessory
frame AKK (with WB bench). The size of the perforation is 9 x 9 mm, center to center 38 mm.

1. Perforated panels for upright tubes
Name Module Size W x H mm Code 1 2
Perforated back panel M500 468 x 389 861 501-49
Perforated back panel M750 718 x 194 861 510-07
Perforated back panel M750 718 x 389 861 511-49
Perforated back panel M750 718 x 612 861 512-07/-49
Perforated back panel, M750 718 x 612 861 701-07/-49
insulated
Perforated back panel M750 718 x 1003 861 514-07/-49
Perforated back panel M900 871 x 389 861 516-49
Perforated back panel M900 871 x 612 861 517-07/49
Perforated back panel M900 871 x 1003 861 519-07/49
Perforated back panel M1000 968 x 389 861 532-49
Perforated back panel M1000 968 x 612 861 538-07/49
Perforated back panel M1000 968 x 1003 861 535-07
3
Perforated back panel M1200 1168 x 389 861 533-49
Perforated back panel M1350 1318 x 389 861 521-49
Perforated back panel M1500 1474 x 389 861 526-49
Perforated back panel M1800 1774 x 389 861 531-49
Fastened to the upright tubes (see page 42).

2. Back panels for upright tubes
Name Module Size Code ESD 4
W x H mm
Back panel M500 468 x 389 861 541-49
Back panel M750 718 x 194 861 550-49
Back panel M750 718 x 389 861 551-49
Back panel M750 718 x 612 861 552-49
Back panel M900 871 x 389 861 556-49
Fastened to the upright tubes (see page 42).

3. Perforated panels for TPH benches 4. Perforated panels for WB benches
Size W x H mm Suitable for Code Code ESD Size W x H mm Suitable for Code ESD
STORAGE SOLUTIONS Perforated panels
1115 x 750 TPH712 RL120 RL120 668 x 500 AKK70, AKK150 ARL70
1415 x 750 TPH715/ 915 RL150 RL150 968 x 500 AKK180 ARL100
1715 x 750 TPH718/ 918 RL180 RL180 Mount on accessory frame AKK (see page 54).
Panel hooks TPH RK1 RK1
Mount on TPH benches with panel hooks RK1. Can also be attached to a
wall with screws (included).

PERFORATED PANELS PERFORATED PANELS
