Shelving system

The Treston shelving system can be built as a combination 1. Standard parts
of cabinets and shelves and can be used as a space Name Size W x D x H mm Code
divider. The shelving system is available in two Standard part 80/30/200 824 x 300 x 2000 C 313 49 001P
standard heights, 200 cm and 240 cm and two widths, Standard part 80/40/200 824 x 400 x 2000 C 314 49 001P
80 cm and 100 cm. Standard part 100/30/200 1024 x 300 x 2000 C 313 49 002P
Standard part 100/40/200 1024 x 400 x 2000 C 314 49 003P
Standard part 100/50/200 1024 x 500 x 2000 C 315 49 001P
Standard part 100/60/200 1024 x 600 x 2000 C 316 49 001P
Standard part 80/40/240 824 x 400 x 2400 C 314 49 002P
Standard part 100/40/240 1024 x 400 x 2400 C 314 49 004P
Standard part 100/50/240 1024 x 500 x 2400 C 315 49 002P
Standard part 100/60/240 1024 x 600 x 2400 C 316 49 002P

2. Extension parts
Name Size W x D x H mm Code
Extension part 80/30/200 804 x 300 x 2000 C 323 49 001P
Extension part 80/40/200 804 x 400 x 2000 C 324 49 001P
1 2 Extension part 100/30/200 1004 x 300 x 2000 C 323 49 002P
Extension part 100/40/200 1004 x 400 x 2000 C 324 49 003P
Extension part 100/50/200 1004 x 500 x 2000 C 325 49 001P
Extension part 100/60/200 1004 x 600 x 2000 C 326 49 001P
Extension part 80/40/240 804 x 400 x 2400 C 324 49 002P
Extension part 100/40/240 1004 x 400 x 2400 C 324 49 004P
Extension part 100/50/240 1004 x 500 x 2400 C 325 49 002P
Load capacity 1000 kg/part Extension part 100/60/240 1004 x 600 x 2400 C 326 49 002P
150 kg/shelf All standard and extension parts include 6 shelves.
width 824 mm

150 kg/shelf
width 1024 mm Shelving cabinets

1. 100/40/200-1
C 344 07 001 (blue), C 344 49 001 (light grey)
Qty Name Size mm Code blue Code light grey
STORAGE SOLUTIONS Shelves and cabinets
! The W x D x H rule 1 Cabinet 1030 x 430 x 2010 C 344 07 000 C 344 49 000
All our dimensions follow a WDH rule, where the first
dimension is the width (W), the middle the depth (D), 100/40/200
and the last the height (H). 4 Shelf 1000 x 400 852 231-49 852 231-49
This cabinet is flat packed.

2. 100/40/200-4
C 344 07 004 (blue), C 344 49 004 (light grey)
Qty Name Size mm Code blue Code light grey
1 Cabinet 1030 x 430 x 2010 C 344 07 000 C 344 49 000
100/40/200
2 Shelf 1000 x 400 852 231-49 852 231-49
2 Perforated panel 983 x 500 852 145-07 852 145-49
3 Drawer 400 834 513-49 834 513-49
This cabinet is flat packed.

1 Move with a pallet truck
2 ! The cabinet can be moved with a pallet truck or a forklift
when the plinth front panel has been removed. Cabinets are
equipped with adjustment screws.
108 Treston - Ergonomic workspaces
