Page 314 - WERA katalógus

Bit-Checks

Bit and holder sets in an extremely compact format

BC Impaktor/30 Bit-Check BC BR 30 Universal + 8001 A ¼" SB

1 Impaktor holder with retaining ring, ring magnet, 20 Impaktor bits and 10
standard torsion bits. The Impaktor technology ensures an above-average
service life even under extreme conditions thanks to a best-possible utilisation
of the material properties and optimally designed geometry, particularly
suitable for use with conventional impact drivers. Holder equipped with a ring
magnet to easily hold longer and heavier screws, also ideal for above-head
work. The rough diamond coating of the bits reduces the danger of any slipping
out of the screw head due to the enhanced frictional resistance
28 bits, 1 Rapidaptor bit holder, 1 adaptor 870/1 (¼" hexagon to ¼" square ),
1 Wera Bit Ratchet, drop-forged full steel design, suitable for ¼" hex bits as
per DIN 3126-C 6.3 and E 6.3, ISO 1173 and Wera series 1 and 4
Code
05057690001 897/4 1 x 1/4"x75 10
Impaktor R
840/1 IMP DC 1 x 4,0x25; 1 x 5,0x25; 1 x 6,0x25
840/1 Z 1 x 3,0x25 Code
Hex-Plus 05073640001 1
851/1 IMP DC 3 x PH 2x25; 2 x PH 3x25 8001 A 1 x 1/4"x87,0;
889/4/1 K
1 x 1/4"x50
851/1 TZ PH 2 x PH 1x25 800/1 TZ 1 x 1,0x5,5x25
855/1 IMP DC 3 x PZ 2x25; 2 x PZ 3x25 840/1 Z 1 x 3,0x25; 1 x 4,0x25; 1 x 5,0x25;
855/1 TH PZ 2 x PZ 1x25 Hex-Plus 1 x 6,0x25; 1 x 8,0x25
867/1 IMP DC 3 x TX 25x25; 2 x TX 30x25; 2 x TX 40x25 851/1 TZ PH 2 x PH 1x25; 3 x PH 2x25; 1 x PH 3x25
®
867/1 TZ TORX 1 x TX 10x25; 1 x TX 15x25; 2 x TX 20x25
855/1 TH PZ 1 x PZ 1x25; 3 x PZ 2x25; 1 x PZ 3x25
867/1 TZ TORX 1 x TX 10x25; 1 x TX 15x25; 1 x TX 20x25;
®
1 x TX 25x25; 1 x TX 30x25; 1 x TX 40x25
867/1 Z 1 x TX 10x25; 1 x TX 15x25; 1 x TX 20x25;
TORX BO 1 x TX 25x25; 1 x TX 30x25
®
870/1 1 x 1/4"x25
? When is the Bit Ratchet needed?

Particularly when the space is confi-
ned and there is not much room for
the tool.
The combination of the double torsion zones in the Impaktor holder
and the torsion zone in the Impaktor bit result in the so-called
TriTorsion system.
