Kraftform Kompakt with Ratchet Function

High working speeds

Kraftform Kompakt 27 RA 1 SB

Application: Suitable for hexagon socket insert bits as per DIN 3126-C 6.3
(ISO 1173) and Wera series 1
Design: Ratchet, fine-tooth design for minimal return angle, switchover
ring (right, locked, left), maximum torque of up to 50 Newton
metres, hexagon blade with / " hexagon chuck, stainless steel
1
4
sleeve, strong permanent magnet
Handle: Kraftform with non-roll feature, multi-component, integrated
magazine

Code
05073660001 800/1 Z 1 x 1,0x5,5x25; 1 x 1,2x6,5x25 1 Kraftform Kompakt 60 RA
851/1 Z PH 1 x PH 1x25; 1 x PH 2x25
855/1 Z PZ 1 x PZ 1x25; 1 x PZ 2x25

Pouch with 89 mm bits
17-piece set
1 hand-held bit holder 816 RA Kraftform with ratchet function, fine-tooth
design for minimal return angle, switchover ring (right, locked, left), maximum
torque of up to 50 Newton metres, / " hexagon chuck with Rapidaptor
1
4
technology i.e. rapid-in, rapid-out, rapid-spin, chuck-all and single-hand
function for rapid bit change, magnetic and 16 bits of 89 mm in length suitable
for holders as per DIN 3126-F 6.3, ISO 1173, or for direct insertion in a power
tool

Code
05051040001 816 RA 1 x 1/4"x142,0 1
800/4 Z 1 x 1,0x5,5x89
840/4 Z 1 x 3,0x89; 1 x 4,0x89; 1 x 5,0x89
Hex-Plus
851/4 Z PH 1 x PH 1x89; 1 x PH 2x89; 1 x PH 3x89
855/4 Z PZ 1 x PZ 1x89; 1 x PZ 2x89; 1 x PZ 3x89
867/4 Z 1 x TX 10x89; 1 x TX 15x89; 1 x TX 20x89;
®
TORX BO 1 x TX 25x89; 1 x TX 30x89

188
