TOOL CASES


                 Tool Case “Basic”                              00
                 empty                                          21

                   > heavy duty A$S material, black
                   > circumferential aluminium frame with D shape rings
                 for the shoulder strap (included)
                   > 3 digit lock and two flip locks for fixation of the cover
                   > strong, ergonomic handle
                   > metal hinges
                   > lid holder with hinge joint mechanism
                   > document compartment in the cover
                   > removable tool board in the lid with nine push in compartments
                 and an elastic loop on the lid side; with ten slim and one large
                 push in compartments on the bottom side
                   > base tray, height 55 mm, can be subdivided by inserts;
                 cover plate with 12 large push in compartments and a flat
                 compartment, can be fixed by popper
                   > load capacity: 15 kg

















                                                                      00 21 05 LE




                             EAN       Dimension exterior (interior) width  Dimension exterior (interior) height  Dimension exterior (interior) depth
                 Article No    003773           mm                        mm                         mm               g
                 00 21 05 LE  05690              65 (  0)                200 (180)                  10 (350)         5680








                 Tool Case “Standard”                           00      > heavy duty A$S material, black
                 empty                                          21      > with circumferential double aluminium frame
                                                                        > register hinges working as lid holder
                                                                        > strong, ergonomic handle
                                                                        > two flip locks, lockable
                                                                        > one removable tool board in the lid with 15 push in compartments
                                                                       on the bottom side and six big push in compartments and a clamp
                                                                       compartment ( 00 mm width) on the lid side, fixed by push button
                                                                        > base tray, height 58 mm, can be subdivided by flexible inserts; cover
                                                                       plate with six large push in compartments, can be fixed by popper
                                                                        > cover and tool plate made of Con Pearl  material
                                                                                                  ®
                                                                        > 20 kg maximum load




                00 21 20 LE




                             EAN       Dimension exterior (interior) width  Dimension exterior (interior) height  Dimension exterior (interior) depth
                 Article No    003773           mm                        mm                        mm               g
                 00 21 20 LE  0  567           80 ( 60)                 175 (170)                 370 (310)           85
                270                                                         Con Pearl  is a registered trademark of PARAT Schönenbach GmbH   Co  KG
                                                                                 ®
