Page 47 - KNIPEX katalógus

MULTIFUNCTIONAL PLIERS

Smooth gripping surface
for a non damaging gripping and flattening,
round shaping (form wire loops)

Profiled gripping surface
to protect the workpiece, flattened for stronger
yet gentle gripping

Clear-cut outside edge
for deburring and widening holes

Pipe grip
for round parts and cables

Universal crimp die
for end sleeves (ferrules) from 0 5 to 2 5 mm²

Stripping
for copper conductors from 0 75 to 1 5 and 2 5 mm²

Shear blade
for cutting copper cable up to
Ø 15 mm (5 x 2 5 mm²)

13 91 200 / 13 92 200 / 13 96 200
in case of models with opening spring integrated in the joint,
the activated locking lever keeps the cutting edges closed
while other functions remain active; the intelligent latching
mechanism enables you to “grip” without opening the pliers
The cutting edge remains closed and protected

Product video

Cutting capacities
Crimping
EAN Stripping capacity capacity
Article No 003773 mm Pliers Head Handles Ø mm mm 2 for cross sections mm² mm² g
13 81 200 0752 0 200 black atramentized polished plastic coated 15 50 0 75 1 5 2 5 0 5 2 5 265
13 82 200 075080 200 black atramentized polished with multi component grips 15 50 0 75 1 5 2 5 0 5 2 5 280
with multi component grips and
13 82 200 T 079972 200 black atramentized polished 15 50 0 75 1 5 2 5 0 5 2 5 28
integrated tether attachment point
insulate with multi component grips,
13 86 200 075097 200 chrome plated 15 50 0 75 1 5 2 5 0 5 2 5 280
8DE tested
13 91 200 075257 200 black atramentized polished plastic coated 15 50 0 75 1 5 2 5 0 5 2 5 265
13 92 200 075103 200 black atramentized polished with multi component grips 15 50 0 75 1 5 2 5 0 5 2 5 280
insulate with multi component grips,
13 96 200 075110 200 chrome plated 15 50 0 75 1 5 2 5 0 5 2 5 280
8DE tested
35
