P. 3
System details HD 1080p camera (1920x1080)
1.8x - 50x magnification*
Instant image capture via USB
Integral 250mm working distance*
image capture Auto or manual focus
via USB
Adjustable LED illumination
* with standard 4D lens
System functions are accessed via an integrated keypad.
§ Zoom in / out § Brightness
§ High contrast mode § Overview
§ Crosshair size / colour § Image capture
Options
Struktura stand External control console
Keep the workspace clear. Provides wide The intelligent control console includes
adjustment of the working distance, with additional functions such as memory save / recall,
ergonomically positioned monitor stand. image capture, overlay grid & dimensioning lines,
Note: VESA monitor interface required for Struktura stand. as well as the convenience of mouse control.
Imaging software
Instantly capture an HD image. The captured images can be
used for further processing, or stored in a variety of formats
Magnification
including BMP, JPEG & TIFF.
(with 24" monitor)
Lens Magnification
3D 1.3x - 36x
4D* 1.8x - 50x
5D** 2.3x - 62x
* standard option with Benchtop stand
**standard option with Struktura stand
Note: An HD (720p) camera option is also available.
