Technical details Stand options

Universal Stand
Optical data A Mantis Compact Mantis Elite
Dimensions: Dimensions:
A = 565mm - 775mm A = 593mm - 802mm
Mantis Compact B = 335mm - 545mm B = 352mm - 622mm
C = 395mm - 605mm
C = 415mm - 624mm
D = 110mm - 320mm D = 103mm - 312mm
Objective lens Working distance Field of view Unpacked weight: Unpacked weight:
C Head 2.1kg Stand 3.3kg Head 3.0kg Stand 3.3kg
D Packed weight: Packed weight:
2x 167mm 45.0mm Head 4.1kg Stand 4.6kg Head 5.0kg Stand 4.6kg
Power:
4x 96mm 27.5mm B 9V DC external plug transformer, available in all worldwide
plug configurations.
6x 73mm 19.2mm
8x 58.5mm 14.3mm Bench Stand
Mantis Compact Mantis Elite
Dimensions: Dimensions:
A = 475mm - 608mm A = 487mm - 620mm
B = 300mm B = 300mm
Mantis Elite / Elite-Cam HD C = 380mm C = 380mm
D = 330mm D = 330mm
E = 256mm max., E = 255mm max.,
Objective lens Working distance Field of view A less working distance less working distance
Unpacked weight: Unpacked weight:
2x 160mm 57.0mm Head 2.1kg Stand 5.0kg Head 3.0kg Stand 5.0kg
E B Packed weight: Packed weight:
Head 4.1kg Stand 8.4kg Head 5.0kg Stand 8.4kg
4x 96mm 34.0mm D C
Power:
100-240VAC 50-60HZ 1.0A max., available in all worldwide
6x 68mm 23.0mm plug configurations.
6x SLWD* 112mm 20.0mm
Articulated Arm
8x 59mm 17.0mm
Mantis Compact Mantis Elite
A
10x 54mm 13.5mm
Dimensions: Dimensions:
A = 880mm A = 880mm
15x 54mm 8.8mm B = 430mm B = 430mm
C = 510mm C = 510mm
B D = 650mm D = 650mm
20x 29mm 6.5mm C E = 290mm E = 290mm
Unpacked weight: Unpacked weight:
Head 2.1kg Stand 11kg Head 3.0kg Stand 11kg
*cannot be used together with 2x or 20x lens E Packed weight: Packed weight:
D Head 4.1kg Stand 13.5kg Head 5.0kg Stand 13.5kg
Power:
9V DC external plug transformer, available in all worldwide
Options plug configurations.
*Ask your sales manager for details about alternative stand options
Floating Stage
Provides smooth and sensitive control allowing for samples to
be accurately inspected. For use with bench stand only. Illumination
Mantis Compact Lighting Data
Episcopic Illuminator
Light intensity measured at subject plane with colour correction filters.
Through-the-lens illumination for the inspection of bore holes 20 LEDs 9,400 LUX Up to 10,000 hours
and complex internal/external features. Iris control for precise
light positioning. Substage illumination (bench stand only)
58 LEDs 2,700 LUX Up to 10,000 hours
UV Lighting
Mantis Elite Lighting Data
Switchable UV-white light illumination for UV inspection Light intensity measured at subject plane with colour correction filters.
applications and fast and accurate fault detection.
24 LEDs 11,000 LUX Up to 10,000 hours
Substage illumination (bench stand only)
58 LEDs 2,700 LUX Up to 10,000 hours
Secondary Link Arm
A secondary link increases total reach of articulated arm to
847.5mm and provides added flexibility and manoeuvrability. Camera
Mantis Elite-Cam HD Camera Data
Floor Stand Sensor type CMOS
Ideal for inspection where subjects are immobile or require a Resolution (H x W) 1600 x 1200 pixels
standing position. For use in conjunction with articulated arm. Sensor size 1/3”
Lift, swing, tilt and rotate capability.
Pixel size 2.8µm
Colour depth 8-bit
Accessories Refresh rate (fps) 17 fps max.
Interface USB2.0
Lens protection caps File formats BMP, JPEG, PNG
Dust cover Power supply USB powered
Replacement LED array
Supplied software ViCapture
