Tweezers | SMD tweezers

SMD tweezers

SMD tweezers – Angled tips

) Suitable for perfect handling of ) Bent shape facilitates optimum
chips and miniature components access to confined spaces and
) Suitable for assembling SMD printed- provides excellent visibility of
circuit boards or ceramic substrates the area to be worked on
) For all models with the suffix CA in
the order number: Special stainless
steel, non-magnetic, non-rusting,
acid-proof, heat-resistant
4.528 Inch / 115 mm Model Weight Material Description
oz. g
102ACA 0.53 15 Special SMD tweezers, angled 45°, with pointed tips for
stainless vertical application.
steel

102ACAX 0.49 14 Special SMD tweezers, angled 45°, with pointed tips for
stainless vertical application. Model same as 102ACA, but
steel reverse clamping action for easy holding.

103ACA 0.53 15 Special SMD tweezers, angled 45°, with slightly wider tips
stainless for vertical application.
steel

SMD tweezers – Round tips straight

) Suitable for gripping and holding ) For all models with the suffix SA in
round components and wires the order number: Special stainless
) Blunted edges prevent damage steel, non-magnetic, non-rusting,
to printed-circuit boards acid-proof, heat-resistant

4.331 Inch/ 110 mm Model Weight Material Description
oz. g
39SA 0.53 15 Special SMD tweezers with round tips, dia. 0.3 mm/.011
stainless Inch. Serrated finger grips for secure handling. For
steel gripping small wires and cylindrical components.

40SA 0.53 15 Special SMD tweezers with round tips, dia. 0.4 mm/.015
stainless Inch. Serrated finger grips for secure handling. For
steel gripping small wires and cylindrical components.

362 Precision Tools
