P. 101

Other supplies
                                             Name                       Size W x D x H mm  Max load kg  Code
                                             Box holder for four pick up boxes  456 x 165 x 48  5  854 042-49
                                             Pick up box                149 x 85 x 48              851 843-00
                                             Utility box                410 x 155 x 90    4        854 041-49
                                             Folder compartment         466 x 90 x 240    4        854 040-49
          Box holder                         LCD monitor holder for perforated panel  120 x 38 x 150  10  890 715-49














          Utility box                        Folder compartment                 LCD monitor holder for perforated
                                                                                panel


          Hook sets




          Ready-made hook sets help you to get started.
          Choose the most suitable hook set for your needs  from the following possibilities:

          Hook set 1    Basic light hook set
          Hook set 2    Basic hook set for hand tools
          Hook set 3    Hook set for perforated tool cabinet
          Hook set 4    All inclusive set for hand tools
          Hook set 5    Hook set for heavy tools in perforated tool cabinet

           Hook sets
                                                            Hooks sets
           Hooks                                            Set 1     Set 2     Set 3     Set 4     Set 5
           included in the sets
           (Code)             L mm      Ø mm      A mm      855 001-51  855 002-51  855 003-51  855 004-51  855 005-51
           R1 (853 207-51)    30        3                             5         15        10        10
           R1 (853 208-51)    50        4                   5         5                   10        10
           R1 (853 211-51)    100       6                                                           10
           R2 (853 218-51)    33        3         17        5         5         5         5         5
           R2 (853 219-51)    43        4         25                                      5         5
           R2 (853 220-51)    43        4         40                                                5
           R10 (853 227-51)   28                  9                                                 5
           R10 (853 228-51)   33                  17                                                5
           R19 (853 231-51)             13                                                5         5                 PERFORATED PANELS AND TOOL STORAGE SYSTEMS  Panel hooks
           R19 (853 232-51)             19                  5         5         5         5         5
           R19 (853 233-51)             22                            5                             5
           R21 (831 646-51)   220       12                            1                             1
           R24 (831 719-51)   80        26                            1         5         7         3
           R24 (852 167-51)   100       42                                      1         2         3
           R29 (853 235-51)   60                                      5                             5
           R30 (853 237-51)   35        4                   5         5         35        40        10
           R33 (832 162-51)   30        90                            1         1         2         1
           R35 (853 239-51)    17                 35                  5                   5         5
           R35 (853 240-51)    17                 55                                                5
           R37 (831 441-51)             60                            1                   3         3
           R42 (838 365-51)    35                 238                 1         1         1         1
           R43 (838 373-51)    42                 238                           1
           Pieces                                           20        45        69        100       107

          L = hook length mm
          A = free gap mm
                                                                                         Treston - Distinctive workshops  101
