Concept upright tubes

Corner bracket
Straight bracket
Horizontal tube
Accessories are attached to the Concept bench with
the aid of upright tubes or a complete, upright tube
module.

The module includes upright tubes, horizontal tube/tubes,
h= corner bracket pair and straight bracket (if module has
Upright tube more than one horizontal tube). The tubes or the module
l=
are attached to the back of the bench.
Upright tubes
Name Size Length (l) mm Code
W x D mm
Upright tube 30 x 60 500 860 991-49
Upright tube 30 x 60 800 860 142-49
Upright tube 30 x 60 996 860 367-49
Upright tube 30 x 60 1359 860 024-49
Upright tube 30 x 60 1582 860 025-49
Horizontal tube M500 860 819-49
Horizontal tube M750 847 402-49
Horizontal tube M900 840 104-49
Horizontal tube M1000 854 656-49
Horizontal tube M1200 854 655-49
! Accessories from page 42 Horizontal tube M1350 850 914-49
Superior range of accessories available for ergonomic Horizontal tube M1500 854 654-49
Concept workstation. Horizontal tube M1800 854 657-49
Corner bracket pair 848 336-49
Straight bracket 851 827-49

Upright tube modules and compatibility
Suitable for bench widths Code Code
C = Concept l =1359 mm l =1582 mm
1000 1200 1500 1800 2000 h =1075 mm h =1300 mm
1 x M750 C C C C C 900 49 001P 900 49 002P
1 x M900 C C C C C 901 49 001P 901 49 002P
The modular (M) size refers to the distance between two 2 x M500 C C 902 49 001P 902 49 002P
upright tubes from the middle of the tube. The modular size 2 x M750 C C C 903 49 001P 903 49 002P
is used to find the appropriate accessories. 2 x M900 C C 904 49 001P 904 49 002P
3 x M500 C C C 905 49 001P 905 49 002P
The upright tubes can also be used separately without the
horizontal tubes. In this case, please order the end cap 4 x M500 C 906 49 001P 906 49 002P
900370-00 for the upright tubes (1 pcs per upright tube). h = module's height measured from Concept bench's top surface.
Load capacity 100 kg / module spacing.
Upright tube modules are available also with 996 mm uprights (h=714 mm).
Item codes: 90X 49 003P.
Upright tube modules include 5 pcs of cable clips for easy cable
WORKBENCHES Concept Aluminium bracket Code
management.

Name
846 554-00
Aluminium bracket

CC cable clip set CC5
bracket (846 554-00) can
Name
be used to attach a single
CC5
Upright tubes
Cable clip set (5 pcs) Suitable for Code A separate aluminium
tube to any bench.
For easy cable management, suitable for up to five cables.
