THERMALTRONICS FORRASZTÁSTECHNIKA

M SZÉRIA (TMT-9000S, MX-500, MX-5000)

600°F Típusú pákahegy 700°F Típusú pákahegy 800°F Típusú pákahegy P = Optimalizált hegykialakítás a jobb
hőátadás érdekében
(325°C - 358°C) (350°C - 398°C) (420°C - 475°C)

TT Eredeti TT Eredeti TT Eredeti Leírás
Cikkszám Cikkszám Cikkszám Cikkszám Cikkszám Cikkszám

M6B325 STTC-040 M7B325 STTC-140 M8B325 STTC-840 Hajlított, hegyes 30° 0.4mm (0.016")

M6BS602 STTC-047P M7BS602 STTC-147P M8BS602 STTC-847P Ferde 60° 1.8mm (0.07")
M6BV010 N/A M7BV010 N/A M8BV010 N/A Ferde 60° 1.00mm (0.04")
M6BV030 N/A M7BV030 N/A M8BV030 N/A Ferde 45° 3.00mm (0.12")
M6BV350 STTC-047 M7BV350 STTC-147 M8BV350 STTC-847 Ferde 60° 1.78mm (0.07")
M6C300 STTC-045 M7C300 STTC-145 M8C300 STTC-845 Kúpos, hegyes 0.40mm (0.016")
M6C301 STTC-016 M7C301 STTC-116 M8C301 STTC-816 Kúpos, hegyes 0.5mm (0.02")
M6CB225 STTC-098 M7CB225 STTC-198 M8CB225 STTC-898 Véső forma Hajlított 30° 1.78mm (0.07")
M6CB226 STTC-099 M7CB226 STTC-199 M8CB226 STTC-899 Véső forma Hajlított 30° 1.5mm (0.06")
M6CH012 N/A M7CH012 N/A M8CH012 N/A Véső forma 30° 1.20mm (0.047") új!!!
M6CH052 N/A M7CH052 N/A M8CH052 N/A Véső forma 30° 5.20mm (0.20") új!!!
M6CH175 STTC-036 M7CH175 STTC-136 M8CH175 STTC-836 Véső forma 30° 2.5mm (0.10")
M6CH176 STTC-037 M7CH176 STTC-137 M8CH176 STTC-837 Véső forma 30° 1.78mm (0.07")
M6CH177 STTC-038 M7CH177 STTC-138 M8CH177 STTC-838 Véső forma 30° 1.5mm (0.06")
M6CH178 STTC-025 M7CH178 STTC-125 M8CH178 STTC-825 Véső forma 30° 1.0mm (0.04")
M6CH179 STTC-025P M7CH179 STTC-125P M8CH179 STTC-825P Véső forma 30° 1.0mm (0.04")
M6CH180 STTC-003 M7CH180 STTC-103 M8CH180 STTC-803 Véső forma 90° 3.0mm (0.12")
M6CH181 STTC-013 M7CH181 STTC-113 M8CH181 STTC-813 Véső forma 90° 3.0mm (0.12")
M6CH250 STTC-017 M7CH250 STTC-117 M8CH250 STTC-817 Véső forma Extra Large 5.0mm (0.20")
M6CP200 STTC-036P M7CP200 STTC-136P M8CP200 STTC-836P Véső forma 30° 2.5mm (0.10")
M6CP201 STTC-037P M7CP201 STTC-137P M8CP201 STTC-837P Véső forma 30° 1.80mm (0.07")
M6CP302 STTC-045P M7CP302 STTC-145P M8CP302 STTC-845P Kúpos, hegyes 0.40mm (0.016")
M6CP303 STTC-001P M7CP303 STTC-101P M8CP303 STTC-801P Kúpos, hegyes Sharp 1.0mm (0.04")
M6CS150 STTC-006 M7CS150 STTC-106 M8CS150 STTC-806 Kúpos, hegyes Sharp 0.4mm (0.016")
M6CS151 STTC-001 M7CS151 STTC-101 M8CS151 STTC-801 Kúpos, hegyes Sharp 1.0mm (0.04")
M6CS152 STTC-022 M7CS152 STTC-122 M8CS152 STTC-822 Kúpos, hegyes Sharp 0.4mm (0.016")
M6CS154 STTC-007 M7CS154 STTC-107 M8CS154 STTC-807 Kúpos, hegyes Sharp 1.0mm (0.04")
M6CS155 STTC-043 M7CS155 STTC-143 M8CS155 STTC-843 Kúpos, hegyes Sharp 0.5mm (0.02")
M6DS525 SMTC-0147 M7DS525 SMTC-1147 M8DS525 SMTC-8147 Pata forma 60° 3.3mm (0.13")

M6DS526 SMTC-0173 M7DS526 SMTC-1173 M8DS526 SMTC-8173 Kés forma 4.83mm (0.19), Increased Tin Area

M6DS529 SMTC-0167 M7DS529 SMTC-1167 M8DS529 SMTC-8167 Pata forma 60° 1.52mm (0.06")
M6K047 N/A M7K047 N/A M8K047
N/A Kés forma 4.70mm (0.185") új!!!
M6K100 SMTC-0161 M7K100 SMTC-1161 M8K100
SMTC-8161 Kés forma 4.83mm (0.19"), Tin Area 2.03mm
M6LB125 SMTC-060 M7LB125 SMTC-160 M8LB125 (0.08")
M6LB126 SMTC-061 M7LB126 SMTC-161 M8LB126
M6LB127 SMTC-062 M7LB127 SMTC-162 M8LB127 SMTC-860 Blade Tip 10.41mm (0.41")
M6LB128 N/A M7LB128 N/A N/A
M6LC650 STTC-065 M7LC650 STTC-165 M8LC650 SMTC-861 Blade Tip 15.75mm (0.62")
M6LR400 STTC-046 M7LR400 STTC-146 M8LR400
M6LR401 SMTC-0170 M7LR401 SMTC-1170 M8LR401 SMTC-862 Blade Tip 22.1 mm (0.87")
M6LR403 STTC-042 M7LR403 STTC-142 M8LR403
N/A Blade Tip 30.00 mm (1.18")

STTC-865 Véső forma Extra Large 5.0mm (0.20")

STTC-846 Ferde Long Reach 60° 1.0mm (0.04")

SMTC-8170 Pata forma Long Reach 60° 3.05mm (0.12")

STTC-842 Véső forma Long Reach 60° 1.78mm (0.07")
